Dimensions

Main Rotor Diameter

48 ft

Tail Rotor Diameter

8 ft 6 in

Length, Rotors Turning

57 ft 9.75 in

Height, Tail Rotor Turning

14 ft 5.5 in

Main Rotor Disc Area

1,809 sq ft

Empty Equipped Weight

5,210 lbs

Mission takeoff weight

9,039 lbs

Maximum takeoff weight

9,500 lbs

Performance

Maximum

Speed  127 mph

Hovering Ceiling In Ground Effect

13,600 ft

Service Ceiling

12,600 ft

Range w/ Maximum Fuel @ SL

318 miles

Powerplant

One 1,400 shp Avco Lycoming T53-L-13 Turboshaft

Armament

Armament varied, but included various machine guns on flexible mounts, and rocket pods on fixed mounts.

• Aug 67 The U.S. Army acquired this aircraft from Bell Helicopter in Fort Worth TX.
• Sep-Dec 67 Assigned Company A, 229th Aviation Battalion, 1st Air Cavalry Division, Republic of Vietnam (RVN) (an Assault Helicopter Company).
• (Operation Bolling, Phu Yen Province).
• 18 Nov 67 Suffered major damage to main rotor during a troop pick-up from a small LZ
• Jan 68 Assigned 355th Aviation Company, 4th Army, Fort Sill, OK
• (Assigned to stateside unit, but stayed in country.)
• Feb 1968-Mar 1969 Assigned Company A, 229th Aviation Battalion, 1st Air Cavalry Division, RVN.
• (Operation Pershing II, Binh Dinh Province).
• (Operation Jeb Stuart, near the DMV).
• (Operation Pegaus/Lam Son 207 relief of Khe Sanh).
• (Operation Carentan II, Quang Tri and Thua Thien Provinces).
• (Operation Delware/Lam Son 216, A Shau Valley).
• (Operation Jeb Stuart III, Quang Tri and Thua Thien Provinces).
• 02 Aug 68 Suffered major damage to main rotor while landing at Quang Tri LZ in Shar Province.
• 31 Jan 69 Hit in hover over LZ while dropping troops in Tay Ninh Province.
• Apr-Aug 69 Assigned Company C, 101st Aviation Battalion, RVN (Air-mobile Company).
• (Operation Lamar Plain, Quang Tin Province).
• 30 May 69 Suffered damage to main rotor from tree strike while hovering in LZ, Phu Bai Province.
• Ol Jun 69 Suffered major damage to main rotor from tree strike while hovering during Med-Evac, Camp Eagle, Phu Bai Province.
• 29 Jun 69 Suffered damage to main rotor from tree strike while landing in LZ to discharge troops, Phu Bai Province.
• 22 Jul 69 Suffered damage to main rotor from tree strike while landing, Phu Bai Province.
• Sep 69-Mar 70 Assigned Company C, 101st Aviation Battalion, 101st Airborne Division, RVN (Air-mobile Company).
• (Operation Randolph Glen, Thua Thien Province).
• (Operation Texas Star, Thua Thien Province).
• (Operations in Cambodia).
• Apr-Aug 70 Assigned B Troop, 2nd Squadron, 17th Cavalry, 101st Airborne Division, RVN (Aerial Reconnaissance)
• (Operations in Cambodia).
• (Operation Jefferson Glenn/Op Ord 13-70, Thua Thien Province).
• Sep-Dec 70 Assigned Bell Helicopter, Ft. Worth, TX
• Jan 71 Assigned Texas National Guard
• Feb 71 Assigned Aviation School, Ft. Rucker, AL.
• Mar-Apr 71 Assigned Supply Division, Ft. Rucker, AL.
• May-Jun 71 Assigned Aviation School, Ft. Rucker, AL.
• Jul 71-Jun 72 Assigned 281st Aviation Company, 5th Army, U.S. Army Reserves.
• Jul 72 Assigned 102nd Army Reverse Command, 5th Army, U.S. Army Reserves.
• Aug 72-Dec 75 Assigned 281st Aviation Company, 5th Army, U.S. Army Reserves.
• Dec 1975 to June 1976 102nd Army Reserve Command, 5th Army, US Army Reserves.
• July 1976 to April 1980 Company B, 24th Avn Bn, Ft Stewart, GA.
• May 1980 to February 1982 to unknown unit or units in Honduras.
• March 1982 to February 1988 West Virginia National Guard.
• It was badly damaged by a lightning strike in February 1988, repaired and handed over to the California National Guard in February 1989 and continued in service through July 1995.
• Handed over to PCAM 23 April 1996.
